Super slim lamp body, 1/2 inch high;
The diffuser plate adopt double-sided frosted plate, more uniform light;
The frame adopt ADC 12, better cooling effect; adopt low-power large LEDs, and LEDs work in low temperature;
The back cover adopt bending, powder spraying; consistent whole effect, and prevent light-leaking;
The driver is designed with high PF(PF>0.9) and is dimmable with most regular dimmers, dimming range up to 10%-100%.
Model | Colour | CCT | Luminous flux(±10%) | LED type | Cutout size | Voltage(V) | Power(W)(±10%) | CRI | PF |
SC-DL09-D04-A1-03RE | 5 CCT adjustable | 2700K 3000K 3500K 4000K 5000K | 540-580 | 2835 | 4-1/4inch | 90-130VAC | 9W | >80 | >0.9 |
SC-DL12-D06-A1-03RE | 820-900 | 6-1/7 inch | 12W | ||||||
SC-DL18-D08-A1-03RE | 1170-1350 | 8-1/4 inch | 18W | ||||||
SC-DL09-D04-AW-3W01RE | 5 CCT adjustable | 2700K 3000K 3500K 4000K 5000K | 540-580 | 2835 | 4-1/4inch | 90-130VAC | 9-6.7-4.5W | >80 | >0.9 |
SC-DL12-D06-AW-3W01RE | 820-900 | 6-1/7 inch | 12-9-6W | ||||||
SC-DL18-D08-AW-3W01RE | 1170-1350 | 8-1/4 inch | 18-13.5-9W |
