High Efficiency Panel Light

High Efficiency Panel Light

LED Square Panel Light can perfectly replace traditional downlight. Using Light Guide Plate, it has the feature of uniform and smooth light beam, low glare rating, low light pollution, and excellent protection from eyestrain. It can be widely used as interior lighting in shops, supermarkets, malls and hospitals, etc.


  • Adopt simple structure, easy to assemble;

  • Energy-saving and eco-friendly, CE RoHS compliant;

  • Select edge-lit structure, more uniform and softer light;

  • High-efficient thermal management design, LEDs and power supply work in low temperature, high stability of continuous working;

  • RAL9003 white lamp body, modern and simple design;

  • Standard warranty: For PS LGP. It is 3 years warranty, For PMMA LGP. it is 5 years warranty.

160 lm w 145 lm w cri 80 ce rohs warranty 5years
Inquire
Inquire
Share
Share
Specifications
Download

Parameters

ModelCCTLumen
(lm±10%)
Power
(±10%)
LED typeVoltagePFLight efficiency
(±10%)
CRI
SC-PSC24CE6060-G36W-P6000-6500K522036W4014220-240V
50/60Hz
>0.9145lm/w>80
SC-PSC24NE6060-G36W-P3800-4200K5220
SC-PSC24WE6060-G36W-P2800-3200K4860
SC-PSC24CE3012-G36W-P6000-6500K5220
SC-PSC24NE3012-G36W-P3800-4200K5220
SC-PSC24WE3012-G36W-P2800-3200K4860
SC-PSC24CE6012-G44W-P6000-6500K638044W
SC-PSC24NE6012-G44W-P3800-4200K6380
SC-PSC24WE6012-G44W-P2800-3200K6075
SC-PSC24CE6060-G36W-H6000-6500K576036W4015220-240V
50/60Hz
>0.9160lm/w>80
SC-PSC24NE6060-G36W-H3800-4200K5760
SC-PSC24WE6060-G36W-H2800-3200K5400
SC-PSC24CE3012-G36W-H6000-6500K5760
SC-PSC24NE3012-G36W-H3800-4200K5760
SC-PSC24WE3012-G36W-H2800-3200K5400
SC-PSC24CE6012-G44W-H6000-6500K704044W
SC-PSC24NE6012-G44W-H3800-4200K7040
SC-PSC24WE6012-G44W-H2800-3200K6600


Size
