Wall washer light effect
It can achieve the traditional wall washer effect,and can also be used for
building dark edge hooking and curved surface lighting
Perfect linear lighting effect
Imported LED brand chips have long lifespan,stable lighting, low light
attenuation and good lighting consistency, Distance from Wall for 4-10CM,
optimal wall washing height is 1-1.5m
Cascade
The longest cascade is 10 m,165 mm can be reduced,
and different lengths can be customized
| Model | Color | Lumen (lm/m) | LED Type | LED Qty. (PCS/M) | DC Voltage(V) | Beam angle | Rated Watt(w/m) | IP |
| SC-2835-07-DT-XX-24-42-18-YY | WW | 2200 | 2835 | 42 | 24 | 20° 35° 45° | 18 | 67 |
| NW | 2230 | 2835 | 42 | 24 | ||||
| W | 2250 | 2835 | 42 | 24 | ||||
| SC-5050-06-DT-RGB-24-48-18-YY | RGB | / | 5050 | 48 | 24 | 40° 50° 60° | 11.5 | 67 |
| SC-5050-06-DT-RGBIC-24-48-18-YY | RGB | / | 5050 | 48 | 24 | 10 | ||
| SC-5050-06-DT-RGBWIC-24-36-18-YY | RGBW | / | 5050 | 36 | 24 | 10 |
Unit: mm/inch
