High efficiency up to 150LM/W.
CRI80 or CRI90 available.
High color consistency, same color tone.
Cuttable to meet different length.
Different watt for demand.
Different IP rate for choice.
Illuminate your world with Signcomplex, the leading LED strip light supplier. With a commitment to innovation, quality, and customer satisfaction, Signcomplex stands as a beacon of excellence in the realm of LED lighting.
| Model | Colour | CCT Range | Lumen (lm/m) | LED type | CRI | PCB width(mm) | Maximum length (m) | Minimum length (mm) | DC voltage (V) | LED quantity (pcs/m) | Rated power (W/m) | IP |
| SC-2835IT-64-PSWW-12 | SWW | 2640K-2840K | 540 | 2835 | >80 | 8 | 5 | 62.5 | 12 | 64 | 3.8 | IP20/64/65/68 |
| SC-2835IT-64-PWW-12 | WW | 2900K-3200K | 570 | |||||||||
| SC-2835IT-64-PNW-12 | NW | 3750K-4280K | 590 | |||||||||
| SC-2835IT-64-PW-12 | W | 6100K-6900K | 610 | |||||||||
| SC-2835IT-128-PSWW-12 | SWW | 2640K-2840K | 1060 | 2835 | >80 | 8 | 5 | 31.25 | 12 | 128 | 7.7 | IP20/64/65/68 |
| SC-2835IT-128-PWW-12 | WW | 2900K-3200K | 1120 | |||||||||
| SC-2835IT-128-PNW-12 | NW | 3750K-4280K | 1160 | |||||||||
| SC-2835IT-128-PW-12 | W | 6100K-6900K | 1210 | |||||||||
| SC-2835IT-16D-PSWW-12 | SWW | 2640K-2840K | 1340 | 2835 | >80 | 8 | 5 | 25 | 12 | 160 | 9.6 | IP20/64/65/68 |
| SC-2835IT-16D-PWW-12 | WW | 2900K-3200K | 1410 | |||||||||
| SC-2835IT-16D-PNW-12 | NW | 3750K-4280K | 1440 | |||||||||
| SC-2835IT-16D-PW-12 | W | 6100K-6900K | 1490 | |||||||||
| SC-2835IT-24D-PSWW-12 | SWW | 2640K-2840K | 1950 | 2835 | >80 | 8 | 5 | 16.7 | 12 | 240 | 14.4 | IP20/64/65/68 |
| SC-2835IT-24D-PWW-12 | WW | 2900K-3200K | 2080 | |||||||||
| SC-2835IT-24D-PNW-12 | NW | 3750K-4280K | 2150 | |||||||||
| SC-2835IT-24D-PW-12 | W | 6100K-6900K | 2210 | |||||||||
| SC-2835IT-64-PSWW-24 | SWW | 2640K-2840K | 540 | 2835 | >80 | 8 | 5 | 125 | 24 | 64 | 3.8 | IP20/64/65/68 |
| SC-2835IT-64-PWW-24 | WW | 2900K-3200K | 570 | |||||||||
| SC-2835IT-64-PNW-24 | NW | 3750K-4280K | 590 | |||||||||
| SC-2835IT-64-PW-24 | W | 6100K-6900K | 610 | |||||||||
| SC-2835IT-128-PSWW-24 | SWW | 2640K-2840K | 1060 | 2835 | >80 | 8 | 5 | 62.5 | 24 | 128 | 7.7 | IP20/64/65/68 |
| SC-2835IT-128-PWW-24 | WW | 2900K-3200K | 1120 | |||||||||
| SC-2835IT-128-PNW-24 | NW | 3750K-4280K | 1160 | |||||||||
| SC-2835IT-128-PW-24 | W | 6100K-6900K | 1210 | |||||||||
| SC-2835IT-16D-PSWW-24 | SWW | 2640K-2840K | 1340 | 2835 | >80 | 8 | 5 | 50 | 24 | 160 | 9.6 | IP20/64/65/68 |
| SC-2835IT-16D-PWW-24 | WW | 2900K-3200K | 1410 | |||||||||
| SC-2835IT-16D-PNW-24 | NW | 3750K-4280K | 1440 | |||||||||
| SC-2835IT-16D-PW-24 | W | 6100K-6900K | 1490 | |||||||||
| SC-2835IT-24D-PSWW-24 | SWW | 2640K-2840K | 1950 | 2835 | >80 | 10 | 5 | 33.3 | 24 | 240 | 14.4 | IP20/64/65/68 |
| SC-2835IT-24D-PWW-24 | WW | 2900K-3200K | 2080 | |||||||||
| SC-2835IT-24D-PNW-24 | NW | 3750K-4280K | 2150 | |||||||||
| SC-2835IT-24D-PW-24 | W | 6100K-6900K | 2210 |
